UM Magazines

Description

Our Magazines only fit our DBM’s found HERE

All UM DBM lengths fit all corresponding length mags, for example our Long Action DBM fits both CIP and XL mags.

Short Mag (2.990″ Inside Mag length) works with all aftermarket REM 700 short actions

Short XL Mag (3.150″ Inside Mag length) works with BAT Machine and any other short action with a load port length 3.150″ and longer

Medium Mag (3.260″ Inside Mag Length) works with Lone Peak, Zermatt, Stiller, and NEW Defiance XM+ spacing

Medium XL Mag (3.400″ Inside mag length) ONLY works with our new Medium length Vesper action at this time

Medium XLR Mag (3.250″ Inside mag length) works only with all XLR Medium Chassis

Long CIP Mag (3.800″ Inside mag length) works with all Rem 700 Clone long actions including Defiance, Lone Peak, Zermatt, Terminus, etc.

Long XL Mag (3.950″ inside mag length) works with BAT Machine actions, Defiance “Seekins Cut” actions, Pierce Engineering Actions 4″ Cut actions, Terminus Kratos X action, Lone Peak 4″ Cut actions, and any other 700 clone action that has a 4″ load port normally used with a Wyatt’s CFE-9 box.

Specifications:

Long DBM weighs 3.7 ounces, Long Mag weighs 2.8 ounces.

Standard M5 footprint, will NOT fit Remington BDL inlet, see below for inlet picture.

But we can open up your BDL inlet to a M5 inlet on HERE!

Side Release Lever- unaffected by recoil due to patent pending design

All parts are 6061 Aluminum, fasteners are stainless steel

3 Round Single stack, Center Feed for all mags

Type 3 Hardcoat Anodize on DBM and Mags, release button and mag lower plate are Cerakoted gray as pictured.

Custom Cerakote and laser engraving options are available per customer request

*** This product has dealer pricing available, email sales@unknownmunitions.com to get set up.
